Welding Robots

Robot SET RMFD19-V166H from OTC-Daihen

Robot SET RMFD19-B6L (S2) from OTC-Daihen

The CM-0401-D wire feed unit is a component that has been specially developed for ARXIS welding power sources.

Wire feeders are used to supply filler metal to the weld joint and are essential for MIG/MAG and TIG cold wire welding. External wire feeder can provide significant advantages over internal wire feeders and are a popular choice for professional welders looking to improve the quality and efficiency of their welding process.

FD19-B6 Robot Base Module

• Simple and slim design only 145 kg weight
• Optimized payload capacity of 6 kg
• Advanced operational performance by high accurate positional repeatability of 0.08 mm
• Easy handling (Teach in)
• Extremely reliable
• Working range of R 1445 mm
• Incl. APS Function (Advanced Parameter Selection)
• Incl. IFC Function (Intuitive Function Control)

This kit incl.
116000009: Basic Robot Module RMFD19-B6
116003003: Transformer case & noise filter for FD19 (CE-KIT)
116007019: Teach Pendant 8m Cable for FD19
116072015: Control Cable 5m for B6, B6L, V8, V8L, V25(FD19)
214003002: Transformer 3kVA
116072003: Operation Box with 5m Cable for FD19
116006028: Printed Circuit Board Relay Unit for FD19 ( 1-32 IN/OUT)

FD19 B6L Robot Base Module
• Simple and slim design only 278 kg weight
• Optimized payload capacity of 6 kg
• Advanced operational performance by high accurate positional repeatability of 0.08 mm
• Ideal for offline teaching
• Extremely reliable
• Large working range of R 2008 mm
• Incl. APS Function (Advanced Parameter Selection)

The Basic Robot Module include:
① Robot Manipulator (NB6L2-CEFC(S2))
② Control Unit FD19 (FD19-CL0000)
③ Teach Pendand for FD19 (FD19TP-DSJNW)
④ Point Mark Assy (L7096C00)
⑤ Transformer case & noise filter for FD19 (CE-KIT)
⑥ Teach Pendant 8m Cable for FD19
⑦ Control Cable 5m for B6, B6L, V8, V8L, V25(FD19)
⑧ Transformer 3kVA
⑨ Operation Box with 5m Cable for FD19
⑩-1 Printed Circuit Board Relay Unit for FD19 ( 1-32 IN/OUT)

For different configuration of the SET, contact us.

Teach Pendant for FD19 from OTC-Daihen

Point mark ASSY from OTC-Daihen

Teach Pendant 8m Cable for FD19 from OTC-Daihen

Teach Pendant 15m Cable for FD19 from OTC-Daihen

Control Cable 5m for B6, B6L, V8, V8L, V25(FD19) from OTC-Daihen

Control Cable 10m for B6, B6L, V8, V8L, V25(FD19) from OTC-Daihen

Control Cable 15m for B6, B6L, V8, V8L, V25(FD19) from OTC-Daihen

Transformer 3kVA from OTC-Daihen

Transformer 5kVA from OTC-Daihen

Transformer 7kVA from OTC-Daihen

Transformer 10kVA from OTC-Daihen

Transformer 12kVA from OTC-Daihen

Transformer 20kVA from OTC-Daihen

Connection terminal block for FD19 from OTC-Daihen
