Industrial camera

CMOS, NULL, 3.5 μm × 3.5 μm, 16384 × 2, , Mono, 2LC fiber connector, M72*0.75, flange focal length 12 mm (0.5"), applicable to F-mount via lens adapter, 132 mm × 76 mm × 57.4 mm (5.2" × 3.0" × 2.3"), 1 Link mode: 73.2 kHz (1-Line), 60 kHz (2-TDI)
2 Link mode: 120 kHz (1-Line), 60 kHz (2-TDI), CE-RoHS;CE-EMC;UL;KC, ,

CMOS, NULL, 3.5 μm × 3.5 μm, 16384 × 2, , Mono, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 76 mm × 76 mm × 42.1 mm (3.0" × 3.0" × 1.7"), Full resolution: 10 kHz (Base), 20 kHz (Medium), 40 kHz (Full), 50 kHz (80-bit)
Improve line rate via Binning: 71 kHz @1-line (full resolution), 60 kHz @2-TDI (full resolution)
Improve line rate via ROI: 120 kHz @1-line (6820 resolution and below), 60 kHz @2-TDI (13650 resolution and below), CE-RoHS;CE-EMC;UL;KC, ,

CMOS, NULL, 3.5 μm, 16384 × 1, , Mono, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 76 mm × 76 mm × 42.1 mm (3.0" × 3.0" × 1.7"), 10 kHz (Base), 20 kHz (Medium), 40 kHz (Full), and 50 kHz (80-bit), CE-RoHS;FCC-SDoC;CE-EMC;UL;KC, ,

CMOS, NULL, 3.5 μm, 16384 × 1, , Mono, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 76 mm × 76 mm × 42.1 mm (3.0" × 3.0" × 1.7"), 10 kHz (Base), 20 kHz (Medium), 40 kHz (Full), and 50 kHz (80-bit), CE-RoHS;FCC-SDoC;CE-EMC;UL;KC, ,

CMOS , NULL, 5 μm, 8192 × 6, , Color, Gigabit Ethernet, compatible with Fast Ethernet, M72 *0.75, optical back focal length: 12 mm (0.5"), 80 mm × 80 mm × 46.3 mm (3.1" × 3.1" × 1.8"), Standard mode: 14 kHz @Bayer 8/Mono 8, 7 kHz @Bayer 10/Mono 10, 4.7 kHz @RGB 8/BGR 8
High-bandwidth mode: 40 kHz @Bayer 8, 20 kHz @Bayer 10, 14 kHz @RGB 8, CE-RoHS;FCC-SDoC;CE-EMC;UL;KC, ,

CMOS , NULL, 5 μm, 8192 × 6, , Color, Gigabit Ethernet, compatible with Fast Ethernet, M72 *0.75, optical back focal length: 12 mm (0.5"), 80 mm × 80 mm × 46.3 mm (3.1" × 3.1" × 1.8"), Standard mode: 14 kHz @Bayer 8/Mono 8, 7 kHz @Bayer 10/Mono 10, 4.7 kHz @RGB 8/BGR 8
High-bandwidth mode: 40 kHz @Bayer 8, 20 kHz @Bayer 10, 14 kHz @RGB 8, CE-RoHS;FCC-SDoC;CE-EMC;UL;KC, ,

CMOS, NULL, 5 μm, 8192 × 6, , Color, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 84 mm × 84 mm × 89 mm (3.3" × 3.3" × 3.5"), 10 kHz (Base), 20 kHz (Medium), 34 kHz (80-bit), CE-RoHS;CE-EMC;KC, ,

CMOS, NULL, 5 μm, 8192 × 6, , Color, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 84 mm × 84 mm × 46.2 mm (3.3" × 3.3" × 1.8"), 10.1 kHz (Base), 20.2 kHz (Medium), 33.7 kHz (80-bit), CE-RoHS;CE-EMC;KC, ,

CMOS, NULL, 5 μm, 8192 × 4, , Mono, Gigabit Ethernet, compatible with Fast Ethernet, M72 *0.75, flange focal length 12 mm (0.5"), 80 mm × 80 mm × 46.3 mm (3.1" × 3.1" × 1.8"), *Standard mode: 14 kHz @Mono 8, 7 kHz @Mono 10/12, 9.4 kHz @Mono 10Packed/Mono 12Packed
*High-bandwidth mode: 29.8 kHz @Mono 8, 20 kHz @Mono 10/Mono 12, CE-RoHS;FCC-SDoC;CE-EMC;UL;KC, ,

CMOS, NULL, 5 μm, 8192 × 4, , Mono, Gigabit Ethernet, compatible with Fast Ethernet, M72 *0.75, flange focal length 12 mm (0.5"), 80 mm × 80 mm × 46.3 mm (3.1" × 3.1" × 1.8"), *Standard mode: 14 kHz @Mono 8, 7 kHz @Mono 10/12, 9.4 kHz @Mono 10Packed/Mono 12Packed
*High-bandwidth mode: 29.8 kHz @Mono 8, 20 kHz @Mono 10/Mono 12, CE-RoHS;FCC-SDoC;CE-EMC;UL;KC, ,

CMOS, NULL, 5 μm, 8192 × 4, , Mono, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 84 mm × 84 mm × 89 mm (3.3" × 3.3" × 3.5"), Multiple lights control disabled or 1-lamp: 20 kHz (Base), 40 kHz (Medium), 81 kHz (Full), 100 kHz (80-bit)
2-lamp: 10 kHz (Base), 20 kHz (Medium), 40 kHZ (Full), 50 kHz (80-bit)
3-lamp: 6 kHz (Base), 13 kHz (Medium), 27 kHZ (Full), 33 KHz (80-bit)
4-lamp: 5 kHz (Base), 10 kHz (Medium), 20 kHZ (Full), 25 kHz (80-bit), CE-RoHS;CE-EMC;KC, ,

CMOS, NULL, 5 μm, 8192 × 4, , Mono, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 84 mm × 84 mm × 46.2 mm (3.3" × 3.3" × 1.8"), 20 kHz (Base), 40 kHz (Medium), 80 kHz (Full), 100 kHz (80-bit), CE-RoHS;CE-EMC;KC, ,

CMOS , NULL, 7 μm × 7 μm, 8192 × 3, , Color, Gigabit Ethernet, compatible with Fast Ethernet, M72 *0.75, flange focal length: 12 mm (0.5"), applicable to F/C-mount and others via adapter, 76 mm × 76 mm × 46.7 mm (3.0" × 3.0" × 1.8"), Standard mode: 14.1 kHz @Bayer·RG·8/Mono·8, 7.7 kHz @Bayer·RG·10, 4.7 kHz @RGB·8/BGR·8
High-bandwidth mode: 33 kHz @Bayer·RG·/Mono 8, 23.2 kHz @Bayer·RG·10, 12.5 kHz @RGB·8/BGR·8, CE-RoHS;CE-EMC, ,

CMOS, NULL, 7 μm, 8192 × 3, , Color, Camera Link; USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 76 mm × 76 mm × 42.1 mm (3.0" × 3.0" × 1.7"), 10.1 kHz (Base), 20.2 kHz (Medium), 33.7 kHz (80-bit)
Increases line rate via ROI: Max. 66.6 kHz (4140 resolution and below), CE-RoHS;CE-EMC;UL;KC, ,

CMOS, NULL, 7 μm, 8192 × 3, , Color, Camera Link; USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 76 mm × 76 mm × 42.1 mm (3.0" × 3.0" × 1.7"), 10.1 kHz (Base), 20.2 kHz (Medium), 33.7 kHz (80-bit)
Increases line rate via ROI: Max. 66.6 kHz (4140 resolution and below), CE-RoHS;CE-EMC;UL;KC, ,

CMOS, NULL, 7 μm × 7 μm, 8192 × 3, , Color, 2LC fiber connector, M72 *0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 132 mm × 76 mm × 57.4 mm (5.2" × 3.0" × 2.3"), 66.6 kHz @Mono 8/Mono 12/RGB 8/BGR 8, CE-RoHS;CE-EMC;UL;KC, ,

CMOS, NULL, 7 μm, 8192 × 2, , Mono, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 76 mm × 76 mm × 42.1 mm (3.0" × 3.0" × 1.7"), 20 kHz (Base), 40 kHz (Medium), 80 kHz (Full), 100 kHz (80-bit), CE-RoHS;CE-EMC;UL;KC, ,

CMOS, NULL, 7 μm, 8192 × 2, , Mono, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 76 mm × 76 mm × 42.1 mm (3.0" × 3.0" × 1.7"), 20 kHz (Base), 40 kHz (Medium), 80 kHz (Full), 100 kHz (80-bit), CE-RoHS;CE-EMC;UL;KC, ,

CMOS, NULL, 7 μm × 7 μm, 8192 × 2, , Mono, 2LC fiber connector, M72 *0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 132 mm × 76 mm × 57.4 mm (5.2" × 3.0" × 2.3"), 200 kHz @ Mono 8
189.4 kHz @ Mono 10
157.8 @ Mono 12, CE-RoHS;CE-EMC;UL;KC, ,

CMOS, NULL, 7 μm, 8192 × 1, , Mono, Camera Link (SDR connector); USB interface for updating firmware, M72*0.75, optical back focal length: 12 mm (0.5"), applicable to F-mount via lens adapter, 76 mm × 76 mm × 42.1 mm (3.0" × 3.0" × 1.7"), 20 kHz (Base), 40 kHz (Medium), 80 kHz (Full), CE-RoHS;FCC-SDoC;CE-EMC;UL;KC, ,

CMOS, NULL, 7 μm, 4096 × 2, , Mono, Gigabit Ethernet, compatible with Fast Ethernet, M42 *1.0, optical back focal length: 12 mm (0.5"), applicable to F-mount, C-mount and others via lens adapter, 62 mm × 62 mm × 41 mm (2.4" × 2.4" × 1.6"), Standard mode: 28 kHz @Mono 8, 14 kHz @Mono 10/12
High-bandwidth mode: 80 kHz @Mono 8/10/12, CE-RoHS;CE-EMC;UL;KC, ,
