Optical Sensor

Laser proximity switch, fix focus, red light, laser class 1, SN=30mm, PNP, 1000Hz, IP67, cable 2m 4-wire, BASIC (without teach-i. Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch, fix focus, red light, laser class 1, SN=30mm, NPN, 1000Hz, IP67, plug M5 4-pin, BASIC (without teach-in). Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch, fix focus, red light, laser class 1, SN=30mm, PNP, 1000Hz, IP67, plug M5 4-pin, BASIC (without teach-in). Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch, fix focus, red light, laser class 1, SN=15mm, NPN, 1000Hz, IP67, moulded plug (pigtail) M8 4-pin, BASIC(. Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch, fix focus, red light, laser class 1, SN=15mm, PNP, 1000Hz, IP67, moulded plug (pigtail) M8 4-pin, 200mmc. Bring your production to new heights with Sensopart vision and sensor

Laser Proximity switch, fix focus, red light, laser class 1, SN=15mm, NPN, 1000Hz, IP67, cable 2m 4-wire, BASIC (without teach-i. Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch, fix focus, red light, laser class 1, SN=15mm , PNP, 1000Hz, IP67, cable 2m 4-wire, BASIC (without teach-. Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch, fix focus, red light, laser class 1, SN=15mm, NPN, 1000Hz, IP67, plug M5 4-pin, BASIC (without teach-in). Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch, fix focus, red light, laser class 1, SN=15mm, PNP, 1000Hz, IP67, plug M5 4-pin, BASIC (without teach-in). Bring your production to new heights with Sensopart vision and sensor

Laser trough-beam sensor, ermitter and receiver, SN=3000mm, NPN, 4000Hz, IP67 cable with connector M8 3-pin 200 mm cable, teach-. Bring your production to new heights with Sensopart vision and sensor

Laser through-beam sensor, ermitter and receiver, SN=3000mm, PNP, 4000Hz IP67,cable with connector M8 3-pin, 200mm cable, teach-. Bring your production to new heights with Sensopart vision and sensor

Laser through-beam sensor, emitter/ receiver, SN=3000mmm, NPN, 4000 Hz, IP67, pigtail 200 mm with connector M8 4-pin, teach-in,. Bring your production to new heights with Sensopart vision and sensor

Laser through-beam sensor, emitter and receiver. Bring your production to new heights with Sensopart vision and sensor

Laser through-beam photoelectric sensor SN= 0...3m, NPN, cable 2m. Bring your production to new heights with Sensopart vision and sensor

Emitter/receiver, receiver Teach-in, SN=0…3m, PNP, cable 2m 4-wire. Bring your production to new heights with Sensopart vision and sensor

Emitter/receiver, receiver Teach-in, SN=0…3m,NPN, plug M5 4-pin. Bring your production to new heights with Sensopart vision and sensor

Description:

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data:

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
0
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
PNP
Temperature range [°C]
-20 ... +50
Connection type
Plug M5, 4-pin
Enclosure rating
IP 67

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating
IP 67

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
PNP
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating
IP 67

Description
Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings
Product data
Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 4-wire, 200 mm
Enclosure rating
IP 67

Laser through-beam sensor, receiver, red light, laser class 1, SN=4000mm, PNP, 4000Hz, IP67, moulded plug (pigtail) M8 4-pin, 20. Bring your production to new heights with Sensopart vision and sensor
