Distance sensors

FT 50 RLA-20-F-L4S Lasertaster mit Analogue sensor, F50, red light, 40µm, 40-60mm, 400Hz, IP67, M12-plug 4 pins. Bring your production to new heights with Sensopart vision and sensor

FT 50 RLA-20-F-K5 Lasertaster mit Analogue sensor, F50, red light,40-60mm, 400 Hz, IP67, cable, 40µm, laser. Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch with analogue output, F50, red light, SN 45-85mm, 40Hz, IP67, M12-plug 4-pin,. Bring your production to new heights with Sensopart vision and sensor

45 ... 85 mm, res. 20 µm, laser, analogue, 0 … 10 V, cable 6 m 5-wire. Bring your production to new heights with Sensopart vision and sensor

45 ... 85 mm, res. 80 µm, laser, analogue, 0 … 10 V, plug M12 4-pin. Bring your production to new heights with Sensopart vision and sensor

FT 50 RLA-40-F-K5 Lasertaster mit Analogue sensor, F50, red light, SN 45-85mm, 400Hz, IP67, cabel, Laser. Bring your production to new heights with Sensopart vision and sensor

Description
Small laser light spot for reliable distance measurement of small objects part detection
Miniature housing and low weight - suitable for robotic applications
High linearity and high repeatability for precise control tasks
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable
Measurement value output via IO-Link

Product data:
Linearity [mm]: 0.25
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 100
Velocity [Hz]: 1000
Interface: IO-Link
Type: Cubic
Light source: Laser, red (Class 1)
Switching output: PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.12
Repeatability [mm]: 0.25
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,1 mm / K
Measurement output: Analog (voltage), IO-Link
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

A follow up product is available. -

Description
Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable
Measurement value output via IO-Link

Product data:
Linearity [mm]: 2
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 30
Working distance max. [mm]: 200
Velocity [Hz]: 1000
Interface: IO-Link
Type: Cubic
Light source: LED, red
Switching output: PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.68
Repeatability [mm]: 1
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,2 mm / K
Measurement output: Analog (voltage), IO-Link
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

Description
Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable
Measurement value output via IO-Link

Product data:
Linearity [mm]: 0.4
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 80
Velocity [Hz]: 1000
Interface: IO-Link
Type: Cubic
Light source: LED, red
Switching output: PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.12
Repeatability [mm]: 0.4
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,1 mm / K
Measurement output: Analog (voltage), IO-Link
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

Description
A follow up product is available.

Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable

Product data:
Linearity [mm]: 2
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 30
Working distance max. [mm]: 200
Velocity [Hz]: 1000
Type: Cubic
Light source: LED, red
Switching output: NPN, PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.68
Repeatability [mm]: 1
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,2 mm / K
Measurement output: Analog (voltage)
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

Description
A follow up product is available.

Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable

Product data:
Linearity [mm]: 2
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 30
Working distance max. [mm]: 200
Velocity [Hz]: 1000
Type: Cubic
Light source: LED, red
Switching output: PNP, PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.68
Repeatability [mm]: 1
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,2 mm / K
Measurement output: Analog (voltage)
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

Description
A follow up product is available.

Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable

Product data:
Linearity [mm]: 0.4
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 80
Velocity [Hz]: 1000
Type: Cubic
Light source: LED, red
Switching output: PNP, PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.12
Repeatability [mm]: 0.4
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,1 mm / K
Measurement output: Analog (voltage)
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

A follow up product is available.

Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable

Description
• Measurement value output via IO-Link
• Minimum weight
• Also suited to smallest installation spaces thanks to minimal dimensions
• Adjustable averaging times
• Laser class 1 for optimum eye safety

Product data

Linearity [mm]
0.4
Sensor principle
Distance sensor with triangulation
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
10
Working distance max. [mm]
70
Velocity [Hz]
1000
Interface
IO-Link
Type
Cubic
Light source
Laser, red (Class 1)
Switching output
PNP/NPN (auto detect)
Amount of swithing outputs
1
Resolution [mm]
0.01
Repeatability [mm]
0.1
Temperature range [°C]
-20 ... +50
Temperature drift [%]
0,01 mm / K
Measurement output
IO-Link
Connection type
Cable, 4-wire, 2 m
Enclosure rating
IP 67

Description
• Measurement value output via IO-Link
• Minimum weight
• Also suited to smallest installation spaces thanks to minimal dimensions
• Adjustable averaging times
• Laser class 1 for optimum eye safety

Product data
Linearity [mm]
0.4
Sensor principle
Distance sensor with triangulation
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
10
Working distance max. [mm]
70
Velocity [Hz]
1000
Interface
IO-Link
Type
Cubic
Light source
Laser, red (Class 1)
Switching output
PNP/NPN (auto detect)
Amount of swithing outputs
1
Resolution [mm]
0.01
Repeatability [mm]
0.1
Temperature range [°C]
-20 ... +50
Temperature drift [%]
0,01 mm / K
Measurement output
IO-Link
Connection type
Pigtail, plug M8, 4-wire, 200 mm
Enclosure rating
IP 67

LLaser distance sensor, working distance 80...400 mm, 2xQ, QA 4…20mA / 0.1...10V, IO-Link, laser class 1, Autodetect (PNP/NPN),m. Bring your production to new heights with Sensopart vision and sensor

Laser distance sensor, working distance 80...400 mm, 2xQ, QA 4…20mA / 0.1...10V, RS485, laser class 1, Autodetect (PNP/NPN), met. Bring your production to new heights with Sensopart vision and sensor

Laser distance sensor, working distance 120…600 mm, 2xQ, QA 4…20mA / 0.1...10V, IO-Link, laser class 2, Autodetect (PNP/NPN), me. Bring your production to new heights with Sensopart vision and sensor

Laser distance sensor, working distance 200…1000 mm, 2xQ, QA 4…20mA / 0.1...10V, IO-Link, laser class 2, Autodetect (PNP/NPN), m. Bring your production to new heights with Sensopart vision and sensor

Laser distance sensor, working distance 80...400 mm, 2xQ, QA 4…20mA / 0.1...10V, IO-Link, laser class 2, Autodetect (PNP/NPN), m. Bring your production to new heights with Sensopart vision and sensor
