Optical Sensor

Proximity switch with background suppression 10-30 V DC, 20-2000mm, 2xPNP antivalent, 250Hz, IR, plug M12, 5pin. Bring your production to new heights with Sensopart vision and sensor

Proximity switch with background suppression 12-240 V AC/DC, 20-2000mm. Bring your production to new heights with Sensopart vision and sensor

20 … 700 mm, 2 x NPN antivalent, red light, bgs, plug M12 5-pin. Bring your production to new heights with Sensopart vision and sensor

20 … 700 mm, 2 x PNP antivalent, red light, bgs, plug M12 5-pin. Bring your production to new heights with Sensopart vision and sensor

Proximity switch with background suppression 12-240 V AC/DC, 20-700mm, 25Hz, red light. Bring your production to new heights with Sensopart vision and sensor

Diffuse sensor with background suppression, 120 ... 600 mm, laser (class 1), 2xQ, Auto-detect, Teach-in, Display, IP 67 / IP 69,. Bring your production to new heights with Sensopart vision and sensor

Diffuse sensor with background suppression, 200 ... 1000 mm, laser (class 1), 2xQ, Auto-detect, Teach-in, Display, IP 67 / IP 69. Bring your production to new heights with Sensopart vision and sensor

Proximity switch on reflector, time of flight measurement, 0.3…70m, laser, analogue 4...20mA, Auto-Detect, N.O./N.C, teach-in, p. Bring your production to new heights with Sensopart vision and sensor

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 1
Sensor principle: Color sensor
Spot size [mm]: 8 x 8
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 150
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 4-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 8 x 8
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 150
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 12
Sensor principle: Color sensor
Spot size [mm]: 8 x 8
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 150
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 8-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 1
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 4-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-

Product data:
Velocity [Hz]: 3000
Amount of colors: 12
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 8-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 500
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 6 x 6
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 32
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

With the FT 55-BH2-NS-L4 Proximity Switches w/ Background Suppression, you can bring your production to new heights. Sensopart vision and sensor.

With the FT 55-BH2-PS-L4 Proximity Switches w/ Background Suppression, you can bring your production to new heights. Sensopart vision and sensor.

Description
Long scanning distance of 1.2 m
BlueLight technology with precisely adjustable background suppression – reliable operation even with highly reflective and glossy backgrounds
Precise scanning distance adjustment by means of potentiometer • Reliable detection of highly transparent or strongly light absorbing objects
Reliable detection even with angles of up to 90°

Product data
Sensor principle: Photoelectric diffuse sensor with Background Suppression
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 3
Working distance max. [mm]: 1200
Velocity [Hz] 600
Adjustment: Potentiometer
Light source: LED, blue
Switching output :PNP
Temperature range [°C] :-20 ... +60
Connection type: Plug M12, 4-pin
Enclosure rating : IP69K, IP 67

Laser distance sensor, working distance 200…1000 mm, 2xQ, 4…20mA / 0.1...10V, RS485, laser class 1, Autodetect (PNP/NPN), metalh. Bring your production to new heights with Sensopart vision and sensor

Laser distance sensor, working distance 200…1000 mm, 2xQ, QA 4…20mA / 0.1...10V, IO-Link, laser class 1, Autodetect (PNP/NPN), m. Bring your production to new heights with Sensopart vision and sensor

Laser distance sensor, working distance 120…600 mm, 2xQ, QA 4…20mA / 0.1...10V, RS485, laser class 1, Autodetect (PNP/NPN), meta. Bring your production to new heights with Sensopart vision and sensor
