Optical Sensor

Description
Smallest RGB color sensor with high switching frequency ≤ 10 kHz
Precise detection of the slightest of contrast differences
Very robust operation despite fluttering and glossy objects
Feedback via „responding light spot“ about quality of taught-in color value

Product data
Amount of colors: 1
Sensor principle: Color sensor
Spot size [mm]: 1 x 5
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 12
Working distance max. [mm]:12
Velocity [Hz]: 2500
Interface: IO-Link
Light source: LED, RGB
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Smallest RGB color sensor with high switching frequency ≤ 10 kHz
Precise detection of the slightest of contrast differences
Very robust operation despite fluttering and glossy objects
Feedback via „responding light spot“ about quality of taught-in color value

Product data
Amount of colors: 1
Sensor principle: Color sensor
Spot size [mm]: 1 x 5
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 12
Working distance max. [mm]: 12
Velocity [Hz]: 10000
Interface: IO-Link
Light source: LED, RGB
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Smallest RGB color sensor with high switching frequency ≤ 10 kHz
Precise detection of the slightest of contrast differences
Very robust operation despite fluttering and glossy objects
Feedback via „responding light spot“ about quality of taught-in color value

Product data
Amount of colors: 1
Sensor principle: Color sensor
Spot size [mm]: 1 x 5
Series:F25 (34 x 20 x 12 mm)
Working distance min. [mm]:12
Working distance max. [mm]:12
Light source:LED, RGB
Switching output:Push-pull
Temperature range [°C]:-20 ... +55
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Smallest RGB color sensor with high switching frequency ≤ 10 kHz
Precise detection of the slightest of contrast differences
Very robust operation despite fluttering and glossy objects
Feedback via „responding light spot“ about quality of taught-in color value

Product data
Amount of colors: 1
Sensor principle: Color sensor
Spot size [mm]_ 1 x 5
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 12
Working distance max. [mm]: 12
Light source: LED, RGB
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Precise detection of the slightest contrast differences
Very robust operation despite fluttering and glossy objects
Simple alignment through very precise and easily visible light spot
Housings that are many times smaller than standard housings – and offer better performance
Very high positioning accuracy with 10 µs scanning

Product data
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 9,5
Working distance max. [mm]: 14,5
Velocity [Hz]: 10000
Light source: LED, white
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Pigtail, plug M12, 4-wire, 150 mm
Enclosure rating: IP 67, IP69

Description
Precise detection of the slightest contrast differences
Very robust operation despite fluttering and glossy objects
Simple alignment through very precise and easily visible light spot
Housings that are many times smaller than standard housings – and offer better performance
Very high positioning accuracy with 10 µs scanning

Product data:
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 9,5
Working distance max. [mm]: 14,5
Velocity [Hz]: 10000
Light source: LED, white
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Precise detection of the slightest contrast differences
Very robust operation despite fluttering and glossy objects
Simple alignment through very precise and easily visible light spot
Housings that are many times smaller than standard housings – and offer better performance
Very high positioning accuracy with 10 µs scanning

Product data:
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 9,5
Working distance max. [mm]: 14,5
Light source: LED, white
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type_: Pigtail, plug M12, 4-wire, 150 mm
Enclosure rating: IP 67, IP69

Description
Precise detection of the slightest contrast differences
Very robust operation despite fluttering and glossy objects
Simple alignment through very precise and easily visible light spot
Housings that are many times smaller than standard housings – and offer better performance
Very high positioning accuracy with 10 µs scanning

Product data:
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 9,5
Working distance max. [mm]: 14,5
Light source: LED, white
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Precise detection of the slightest contrast differences
Very robust operation despite fluttering and glossy objects
Simple alignment through very precise and easily visible light spot
Housings that are many times smaller than standard housings – and offer better performance
Very high positioning accuracy with 10 µs scanning

Product data:
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 9,5
Working distance max. [mm]: 14,5
Velocity [Hz]: 25000
Light source: LED, white
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Precise detection of the slightest contrast differences
Very robust operation despite fluttering and glossy objects
Simple alignment through very precise and easily visible light spot
Housings that are many times smaller than standard housings – and offer better performance
Very high positioning accuracy with 10 µs scanning

Product data:
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 9,5
Working distance max. [mm]: 14,5
Velocity [Hz]: 25000
Light source: LED, white
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Pigtail, plug M12, 4-wire, 150 mm
Enclosure rating: IP 67, IP69

Description
Precise detection of the slightest contrast differences
Very robust operation despite fluttering and glossy objects
Simple alignment through very precise and easily visible light spot
Housings that are many times smaller than standard housings – and offer better performance
Very high positioning accuracy with 10 µs scanning

Product data:
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 9,5
Working distance max. [mm]: 14,5
Light source: LED, white
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Precise detection of the slightest contrast differences
Very robust operation despite fluttering and glossy objects
Simple alignment through very precise and easily visible light spot
Housings that are many times smaller than standard housings – and offer better performance
Very high positioning accuracy with 10 µs scanning

Product data:
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 9,5
Working distance max. [mm]: 14,5
Light source: LED, white
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Pigtail, plug M12, 4-wire, 150 mm
Enclosure rating: IP 67, IP69

Photoelectric diffuse sensor with background suppression, 150 mm, laser, Auto-Detect, teach-in, pigtail with plug M8 4-pin, IP 6. Bring your production to new heights with Sensopart vision and sensor

Photoelectric diffuse sensor with background suppression, 150 mm, laser, Auto-Detect, teach-in, cable 150 mm with plug M8 4-pin,. Bring your production to new heights with Sensopart vision and sensor

Photoelectric diffuse sensor with background suppression, 150 mm, laser, Auto-Detect, teach-in, metal plug M8 3-pin, IP 67 & IP. Bring your production to new heights with Sensopart vision and sensor

Photoelectric diffuse sensor with background suppression, 150 mm, laser, Auto-Detect, teach-in, plug M8 3-pin, IP 67 & IP 69,IO-. Bring your production to new heights with Sensopart vision and sensor

Photoelectric diffuse sensor with background suppression, 120 mm, laser, Auto-Detect, teach-in, metal plug M8 4-pin, IP 67 & IP. Bring your production to new heights with Sensopart vision and sensor

Photoelectric diffuse sensor with background suppression, 150 mm, laser, Auto-Detect, teach-in, cable 2 m 4-wire, IP 67 & IP 69,. Bring your production to new heights with Sensopart vision and sensor

Photoelectric diffuse sensor bgs, red light, teach-in, 150 mm, laser, Auto-Detect, teach-in, plug M8 4-pin, IP 67 & IP 69, IO-Li. Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch bgs, red light, teach-in (button and input), 24 VDC, NPN, N.O./N.C., cable with plug M8 4-pin For thispro. Bring your production to new heights with Sensopart vision and sensor

Laser proximity switch bgs, red light, teach-in (button and input), 24 VDC, PNP, N.O (N.C.), cable with plug M8 4-pin For thispr. Bring your production to new heights with Sensopart vision and sensor
